High Quality Polyurethane Foaming Machine /PU Casting Machine /Polyurethane Casting Machine for Sealing Strip

Basic Info.

Model NO.	LXPU-M210
Application	Polyurethane Door Gasket
Flow Rate	1-4G/S
Casting Width	Max. 1200mm or Customized
Casting Length	Max. 2200mm or Customized
Voltage	380V 50/60Hz
Machine Type	Low Pressure PU Foaming Machine
Material	Isocyanate and Polyol(ISO and Pol)
Power	20kw
Transport Package	Plywood Case Packing
Specification	4500*2800*2200mm
Trademark	Lingxin
Origin	China
HS Code	8477409000
Production Capacity	20 Sets/Month

Product Description

LXPU- M210 type sealing strip casting machine is newly developed by Lingxin company based on learning and absorbing advanced techniques, combining with the characteristics of rapid foaming and molding of polyurethane. It is widely used in the foaming production of electric cabinet door panel, automobile air filter and other sealing strip products, perfectly avoid factors which cause sealing strip quality problems like manual sticking, time wasting, energy wasting, and bad looking corners etc.

Structure Features:
1. Sandwich type material tanks, good heat preservation2. The adoption of PLC touch screen human-computer interface control panel makes the machine easy to use and operating situation was clear.3. Mixing head connected with operation system, easy for operation.4. The adoption of new type mixing head makes the mixing even, low noise, machine sturdy and durable.5. Boom swing length according to the requirement, multi-angle rotation, easy and fast6. High precision pump lead to measuring accurately 7. Easy for maintenance, operation and repair.8. Low energy consumption.9. Auto sensing liquid level

Technical Parameter:

Total power: 20KW

Power: supply: 380V 50HZ

Compressed air: 0.6-0.8MPa

Casting Flow Rate: 1-4g/s

Weight: 2500kg

Rotated speed: 6000rpm

Mix type: Dynamic

Material tank volume: 80L

Mix range: A: B= 100 : 25-70

Measure accuracy: around 0.5%

Our company:Certificate:Welcome to contact with us /send inquiry for more details of machines. We will reply you ASAP. Thanks.
